| Product Model
: |
AS 1390(Australian Standard)
|
|
 |
| AS
1390 ( Australian Standard £© |
M5 |
M6 |
M8 |
M10 |
M12 |
M16 |
M20 |
| Screw Length when Bolt Length ¡Ü125L |
16+2.00 |
18+2.50 |
22+3.00 |
26+3.50 |
30+4.00 |
38+4.50 |
46+5.00 |
| When Bolt Length but ¡Ü200
- L |
22+2.00 |
24+2.50 |
28+3.00 |
32+3.50 |
36+4.00 |
44+4.50 |
52+5.00 |
| When Bolt Length but ¡Ü200£¾200 L |
|
|
|
45+3.50 |
49+4.00 |
57+4.50 |
65+5.00 |
| Reduced Shank (Grade 8g) D |
MAX |
4.42 |
5.30 |
7.10 |
8.90 |
10.70 |
14.55 |
18.20 |
| MIN |
4.36 |
5.23 |
7.02 |
8.82 |
10.62 |
14.47 |
18.12 |
| Normal Shank D3 |
MAX |
5.00 |
6.00 |
8.00 |
10.00 |
12.00 |
16.00 |
20.00 |
| MIN |
4.52 |
5.52 |
7.42 |
9.42 |
11.30 |
15.30 |
19.16 |
| Square
Nack Across Flats S |
MAX |
5.48 |
6.48 |
8.58 |
10.58 |
12.70 |
16.70 |
20.84 |
| MIN |
4.52 |
5.52 |
7.42 |
9.42 |
11.30 |
15.30 |
19.16 |
| Lenght
of Square Neck
H2 |
MAX |
3.10 |
3.60 |
4.80 |
5.80 |
6.80 |
8.90 |
10.90 |
| MIN |
2.50 |
3.00 |
4.00 |
5.00 |
6.00 |
8.00 |
10.00 |
| Head Diameter
D2 |
MAX |
11.25 |
13.50 |
18.00 |
22.50 |
27.00 |
36.00 |
45.00 |
| MIN |
11.14 |
12.40 |
16.90 |
21.20 |
25.70 |
34.40 |
43.40 |
| Head Height H |
MAX |
3.10 |
3.60 |
4.80 |
5.80 |
6.80 |
8.90 |
10.90 |
| MIN |
2.50 |
3.00 |
4.00 |
5.00 |
6.00 |
8.00 |
10.00 |
| When Bolt Length but ¡Ü200 Tolerance
L2
DiameterM5 - M20
|
£¼20 |
20-30 |
35-50 |
55-80 |
90-120 |
130-150 |
160-180 |
¡Ý200 |
| +0.90 |
+1.05 |
+1.25 |
+1.50 |
+1.75 |
+2.00 |
+4.00 |
+4.60 |
| -0.90 |
-1.05 |
-1.25 |
-1.50 |
-1.75 |
-2.00 |
-4.00 |
-4.60 |
| Max Rod Length |
|
200 |
250 |
400 |
400 |
400 |
500 |
500 |
|
|
